HYFD6飞碟款厂房灯
产品介绍
功率范围：
HYFD6-60W
HYFD6-100W
HYFD6-150W
HYFD6-200W
HYFD6-240W
HYFD6-300W
HYFD6-400W
产品中心
经典设计出发，提供适合的产品
技术参数表
No. | 参数名称 | 规格型号及参数表（带驱动） | |||||||
1 | 型号 | FD6-100W | FD6-100W | FD6-150W | FD6-200W | FD6-240W | FD6-300W | FD6-400W | |
2 | 功率 | 60W | 100W | 150W | 200W | 240W | 300W | 400W | |
3 | 电压范围 | AC150-260V | AC150-260V | AC150-260V | AC150-260V | AC150-260V | AC150-260V | AC150-260V | |
4 | 灯具效率 | ≥95% | ≥95% | ≥95% | ≥95% | ≥95% | ≥95% | ≥95% | |
5 | 功率因数PF | ≥0.95 | ≥0.95 | ≥0.95 | ≥0.95 | ≥0.95 | ≥0.95 | ≥0.95 | |
6 | 总谐波 THD | ≤15% | ≤15% | ≤15% | ≤15% | ≤15% | ≤15% | ≤15% | |
7 | 耐压 | 1500V | 1500V | 1500V | 1500V | 1500V | 1500V | 1500V | |
8 | 角度 | 120°/90°/60° | 120°/90°/60° | 120°/90°/60° | 120°/90°/60° | 120°/90°/60° | 120°/90°/60° | 120°/90°/60° | Optional |
9 | 显色指数CRI Ra | ≥80/70 | ≥80/70 | ≥80/70 | ≥80/70 | ≥80/70 | ≥80/70 | ≥80/70 | Optional |
10 | 色温CCT | 5700±300K | 5700±300K | 5700±300K | 5700±300K | 5700±300K | 5700±300K | 5700±300K | Optional |
11 | 光效 (lm) | 115-160 | 115-160 | 115-160 | 115-160 | 115-160 | 115-160 | 115-160 | Optional |
12 | 环境温度 | -20~40° C | -20~40° C | -20~40° C | -20~40° C | -20~40° C | -20~40° C | -20~40° C | |
13 | 寿命 | 30000 hrs | 30000 hrs | 30000 hrs | 30000 hrs | 30000 hrs | 30000 hrs | 30000 hrs | |
14 | 浪涌 | ≥6K | ≥6K | ≥6K | ≥6KV | ≥6KV | ≥6KV | ≥6KV | |
15 | 防护等级IP | IP 65 | IP 65 | IP 65 | IP 65 | IP 65 | IP 65 | IP 65 | |
