Maintenance-free LED explosion-proof lights XL618FB-1
The input voltage: 220V/50HZ
Explosion-proof marks: Exd II C T6 Gb
The rate voltage: 220V
source type: LED
Power: 30-200W
Lighting effect: 110lm/W
Color Temperature: 5700k
Protection Grade: IP66
The anti-corrosion: WF1/WF2
Work environment:-400C-+500C
Inlet thread: G3/4"
Scope of application
Suitable for anti-explosive gas environment zone 1, 2;
Suitable for IIA.IIB.IIC explosive gas environment;
Suitable for combustible dust environment zone 21, 22;
Applicable to the temperature classification of T1~T6 environment;
Suitable for oil production, refining, storage, chemical, medical, textile, military and military facilities and other explosive dangerous environment;
It is compatible with all kinds of explosion-proof lamps and lanterns of our company.
Technical Parameters
Model | Model | Power(W) | Luminous(lm) | Life(h) |
XL618FB-1 | LED | 20 | 2200 | 50000 |
XL618FB-1 | LED | 30 | 3300 | 50000 |
XL618FB-1 | LED | 40 | 4400 | 50000 |
XL618FB-1 | LED | 50 | 5500 | 50000 |
XL618FB-1 | LED | 120 | 13200 | 50000 |
XL618FB-1 | LED | 150 | 16500 | 50000 |
XL618FB-1 | LED | 180 | 19800 | 50000 |
XL618FB-1 | LED | 200 | 22000 | 50000 |
XL618FB-1 | LED | 240 | 26000 | 50000 |
XL618FB-1 | LED | 300 | 33000 | 50000 |
XL618FB-1 | LED | 400 | 44000 | 50000 |
